| Connected Sensor | Point Sensor |
|---|---|
| Target Substance | Acid, Alkali, Water, Organic Solvents |
| Number of Channels | 1-N Channels (Multi-Channel) |
| Measurement Display | 4-Digit FND |
| Alarm Indication | Visual: 2-Alarm LEDs, Trouble LED, Beacon Light Audible: Buzzer Sound (> 75dB) |
| Main Power Supply | AC 220V 50/60Hz |
| Operating Power | DC 24V |
| Power Consumption | Varies by Number of Channels or Order Specifications |
| Power Backup | Ni-Cd Capacitor (> 30 Minutes) (Optional) |
| Relay Contact | RELAY 1A/250V Upon Leak Detection |
| Communication Method | RS-485 Modbus (Optional) |
| Operating Temperature | -20 to 60℃ |
| Operating Humidity | 5-99% RH (Non-Condensing) |
| Enclosure Material | SPCC |
| Enclosure Dimensions | Varies by Number of Channels |
